    Product
    HX-10U Industrial VNIR(400-1000nm) Hyperspectral Camera
    The HX-10U industrial-grade hyperspectral camera is based on the prism-grating dispersion spectroscopic hyperspectral imaging technology independently researched and developed by HHIT. It exhibits numerous outstanding advantages, including high spectral resolution, high efficiency, good consistency, and simplicity in use. In industrial applications, where high-speed, robust, and stable equipment performance is a prerequisite, the HX-10U excels with its high frame rate and large field of view, capable of meeting the higher efficiency requirements of industrial users. Its remarkable cost-effectiveness enables customers to gain a more efficient return on investment. Moreover, the HX-10U hyperspectral camera is endowed with flexible pixel binning and band selection functions, which significantly reduce the difficulty of on-line data transmission and processing for users. It is widely used in industrial sorting, precision agriculture, food inspection, pharmaceutical manufacturing, environmental monitoring, and other fields.

    Application Fields

    Industrial sorting

    Precision agriculture

    Food inspection

    Pharmaceutical manufacturing

    Environmental monitoring

    Application Cases

    On-line Classification and Recycling of Plastic Waste
    The HX-10U visible-near infrared hyperspectral camera, when used together with the automatic sorting software and deep learning algorithms developed by HHIT, can accurately and rapidly classify plastic waste with different colors. The maximum sorting speed can reach over 5 m/s, realizing the fast, precise, and automated sorting and recycling of plastics. This not only helps customers create higher economic value but also promotes the development of the circular economy.

    Functional Features

    More authentic and accurate spectral data

    Higher speed and greater flexibility

    Larger field of view range

    Higher cost-effectiveness

    Specifications


    TECHNICAL SPECIFICATIONS

    HX-10U

    Spectral Dispersion Method

    Transmission Grating Spectroscopy

    Spectral range

    400-780nm

    Spectral resolution

    ≤ 2.5nm

    F-number

    F/2.6

    Sensor

    CMOS

    Data interface

    CameraLink

    Power supply

    12V DC ,<10 W

    Pixelsize

    9μm x9 μm

    Bit depth

    12bit

    Spatial pixels

    ≥1500

    Spectral bands

    360(2x)

    Field of View (FOV)

    ≥65°@f=8mm

    Instantaneous Field of View (IFOV)

    3.125mrad@f=8mm

    Frame rate(at full bands)

    ≥750fps(4x)

    Lens mount

    C-Mount

    Dimensions

    220*80*80mm (excluding lens)

    Weight

    <2.5kg

    Operating temperature

    ‘0-40℃

    Storage temperature

    ‘0-50℃

    Software

    Data Acquisition Software + SDK
